松下 AU-XPD3MC P2 读卡器 驱动器 高速Thunderbolt?3接口的“expressP2驱动器” 提高了4K/高帧频视频制作工作流程的速率

北京风清扬摄影器材有限公司 销售电话 18612707474

卡槽可支持expressP2卡、P2卡或MicroP2卡（需配置适配器）。

AU-XPD3MC有助于提高Varicam 4K/高帧频视频制作工作流程的速率。

"expressP2 drive" with High-Speed Thunderbolt™ 3 Interface Speeds up Video Production Workflow of 4K/high-frame-rate

The AU-XPD3 Memory Card Drive "expressP2 drive" uses the Thunderbolt™ 3 interface to achieve high speed data transfer. The expressP2 card B series are developed as recording media for the Panasonic VariCam series camera, due to record 4K/highframe-rate video. The AU-XPD3 takes full advantage of the high data transfer performance (maximum 10 Gbps*) of this media, thus achieving about four times*1 faster transfer speed than its predecessor, the AU-XPD1/USB 3.0. When two AU-XPD3 units are daisy-chained, data can be transferred at an increased speed of 17.6 Gbps.*

The card slot accommodates an expressP2 card, P2 card or microP2 card (adaptor required). The AU-XPD3 contributes to speedier 4K/high-frame-rate video production workflows using VariCam.

• * The actual data transfer speed and data transfer time depend on the system performance.

High-speed Thunderbolt™ 3 Interface

The high-speed Thunderbolt™ 3 interface incorporated in the AU-XPD3 is capable of transferring data at a maximum speed of 40 Gbps, which is eight times faster than the transfer speed of USB 3.0, and also supports daisy-chain connection of up to six devices.

As a next-generation standard interface, it is used with many Windows PCs and Mac computers, and its application is expanding widely into various products, such as hard-disk drives and other storage devices as well as Thunderbolt™ 2 conversion adaptors.

Transfer Speed of 10 Gbps* Reduces Transfer Time to 1/4

The Thunderbolt™ 3 interface maximizes the high data transfer performance of the expressP2 card B series. The maximum transfer speed of 10 Gbps* (measured value) enables offloading of 512 GB content (AVC-Intra 4K422/24p recording of about three hours) in approximately seven minutes.*

• * The actual data transfer speed and data transfer time depend on the system performance.

Increasing Transfer Speed with a Daisy-chain Connection

The AU-XPD3 supports daisy-chain connection. When two expressP2 drive units are used to simultaneously access two expressP2 cards, the transfer speed increases to 17.6 Gbps* maximum (measured value). This enables offloading of 1 TB content (about six hours) in approximately eight minutes.*

• * The actual data transfer speed and data transfer time depend on the system performance.

Supports expressP2, P2 and microP2 Cards

The card slot (one slot) accommodates an expressP2 card, P2 card or microP2 card (adaptor required). Thus, the AU-XPD3 can be used not only with the VariCam series but also with the P2HD series.*

• * A transfer speed of 10 Gbps is attained only when the expressP2 card B series is used. When another type of P2 card is used, the transfer speed is restricted by the transfer speed of the P2 card used.

Specifications

• * Specifications are subject to change without notice.
